DAQ FMC Modules:

FMC Modules with both Analog to Digital and Digital to Analog sections.

FMC-DAQ2P5

FMC-DAQ2P5
  • ADC12J2700 – 12bit 2.7GSPS JESD204B.
  • LM95233 for ADC temperature monitoring.
  • JESD204B via HPC connector, 8 lanes 5.4Gbps per lane.
  • AD9136 – 16-bit dual channel 2.8GSPS JESD204B DAC.
  • HMC7044 – High performance 3.2GHz JESD204B jitter attenuator.

Product Details...

FMC-FADB

FMC-FADB
  • FMC HPC Connector (high-pin count with 400 pin high-speed array connector)
  • QSE Connector Compatible with Samtec EQRF
  • 3x ADC Chips from Linear Technology: LTC2175-14

Product Details...

FMC110

FMC110
  • Dual – A/D – D/A Channel Operation
  • 2-Channels 12-bit 1.0 Gsps A/D
  • 2-Channels 16-bit 1.0 Gsps D/A
  • VITA 57.1-2010 compliant
  • Conduction Cooled – Standard Option

Product Details...

FMC121

FMC121
FMC-HPC ADC Board Click for full size Image. Two Channel 16-Bit A/D up to 1.0 Gsps Two Channel 16-Bit D/A up to 1.4 Gsps The FMC121 provides two 16-bit A/D channels up to 1Gsps and two 16-bit D/A channels up to 1.4 Gsps data rate with a 2.8 GSPS update rate. The design is based...

Product Details...

FMC142

FMC142
  • Two-channel, 16-bit A/D up to 370 MSPS
  • Two-channel, 16-bit D/A up to 2.5 GSPS
  • VITA 57.1-2010 compliant
  • JESD204B serial interface

Product Details...

FMC144

FMC144
  • Four-channel, 16-bit A/D up to 370 MSPS
  • Four-channel, 16-bit D/A up to 2.5 GSPS
  • VITA 57.1-2010 compliant
  • JESD204B serial interface
  • Conduction-cooled – Standard Option

Product Details...

FMC150

FMC150
  • VITA 57.1-2010 compliant
  • Conduction Cooled – Standard Option
  • Single ended AC-coupled analog signals.
  • 6 MMCX/SSMC connectors available from the front panel

Product Details...

FMC151

FMC151
  • VITA 57.1-2010 compliant
  • Conduction Cooled – Standard Option
  • Single ended DC-coupled analog signals.
  • Digitally controlled offset correction

Product Details...

FMC160

FMC160
  • One ADC12D1800: Single channel 12-bit 3.6Gsps
  • One AD9129: Single channel 14-bit D/A up to 5.6 Gsps (2.8Gsps without 1:2 interpolation) - LVDS
  • VITA 57.1-2010 compliant
  • Conduction Cooled – Standard Option

Product Details...

FMC170

FMC170
  • Single-channel, 10-bit A/D up to 5Gsps
  • Single-channel, 10-bit D/A up to 5Gsps
  • VITA 57.1-2010 compliant
  • Conduction-cooled - Standard Option
  • AC-coupled analog signals

Product Details...

FMC176

FMC176
  • VITA 57.1-2010 compliant
  • Conduction Cooled – Standard Option
  • Single ended AC-coupled analog signals.
  • 10 MMCX/SSMC connectors available from the front panel

Product Details...

RFM-ADAFF22

RFM-ADAFF22
  • 2-ch
  • impedance 50-ohm single-ended
  • Cross Talk 100dB@10MHz, 80dB@30MHz
  • S/N 82dB or over
  • LPF 400KHz-30MHz@-3dB

Product Details...

RFM-ADAFF62

RFM-ADAFF62
  • 6-ch
  • impedance 50-ohm single-ended
  • Cross Talk 100dB@10MHz, 80dB@30MHz
  • S/N 82dB or over
  • LPF 400KHz-30MHz@-3dB

Product Details...

SMT-FMC311

SMT-FMC311
  • VITA57.1 FMC-LPCTM (subset, no MGT) mezzanine.
  • One dual channel ADC.
  • One dual channel DAC.
  • PLL clock synthesizer.
  • External clock and trigger inputs.

Product Details...
