OpenVPX Integrations (Clock, RF, Ethernet, GPS etc.)

Our OpenVPX other COTS integrations (Clock, RF, Ethernet, GPS etc.):

vi010 – RF transceiver

vi010 – RF transceiver
  • TI KeyStone Multicore C667x family of processors
  • Stratix V family in the KF40 (1517 FBGA) package
  • Complies with OpenVPX MOD3-PAY-3F2U-16.2.12-2 module profile
  • RF coverage from 400Mhz to 3.0GHz*
  • Time Domain Duplex (TDD) and Frequency Domain Duplex (FDD) compatible

Product Details...

vi011 – Medium speed clock

vi011 – Medium speed clock
  • TI KeyStone Multicore C667x family of processors
  • Stratix V family in the KF40 (1517 FBGA) package
  • Complies with OpenVPX MOD3-PAY-3F2U-16.2.12-2 module profile
  • External clock input and onboard VCO
  • External reference input and on board reference (30.72MHz)
  • External 1PPS, Sync and Trigger inputs
  • Eight synchronized clock outputs (34.375MHz-250MHz)

Product Details...

vi012 – High speed Clocking

vi012 – High speed Clocking
  • TI KeyStone Multicore C667x family of processors
  • Stratix V family in the KF40 (1517 FBGA) package
  • Complies with OpenVPX MOD3-PAY-3F2U-16.2.12-2 module profile
  • xternal clock input and onboard VCO
  • External reference input and onboard reference (30.72MHz)
  • External 1PPS, Sync, and Trigger inputs
  • Eight synchronized clock outputs (34.375MHz-4.4GHz)

Product Details...

vi013 – 4 Port Ethernet

vi013 – 4 Port Ethernet
  • TI KeyStone Multicore C667x family of processors
  • Stratix V family in the KF40 (1517 FBGA) package
  • Complies with OpenVPX MOD3-PAY-3F2U-16.2.12-2 module profile
  • 4 x 10/100/1000Mbps Ethernet Ports
  • LPC FMC: Pin compatible with FMC carriers
  • 125MHz Oscillator for the MAC

Product Details...

vi014 – GPS Receiver

vi014 – GPS Receiver
  • TI KeyStone Multicore C667x family of processors
  • Stratix V family in the KF40 (1517 FBGA) package
  • Complies with OpenVPX MOD3-PAY-3F2U-16.2.12-2 module profile
  • Primary station
  • GPS receiver
  • SFP x1

Product Details...

vi015 – 10Ch. optical link

vi015 – 10Ch. optical link
  • TI KeyStone Multicore C667x family of processors
  • Stratix V family in the KF40 (1517 FBGA) package
  • Complies with OpenVPX MOD3-PAY-3F2U-16.2.12-2 module profile
  • Ten independent transmit channels
  • Ten independent receive channels
  • High channel capacity: 6.25Gbps or 10Gbps per direction (TX/RX)

Product Details...

vi016 – Dual QSFP

vi016 – Dual QSFP
  • TI KeyStone Multicore C667x family of processors
  • Stratix V family in the KF40 (1517 FBGA) package
  • Complies with OpenVPX MOD3-PAY-3F2U-16.2.12-2 module profile
  • Dual QSFP+
  • Conduction cooled compatible
  • 1.65V to 3.3V VADJ operation

Product Details...

vi017 – Dual Gigabit Ethernet

vi017 – Dual Gigabit Ethernet
  • TI KeyStone Multicore C667x family of processors
  • Stratix V family in the KF40 (1517 FBGA) package
  • Complies with OpenVPX MOD3-PAY-3F2U-16.2.12-2 module profile
  • Dual 1 GbE (1000BASE-T) over RJ45
  • 1.8V to 3.3V VADJ operation
  • HPC (High-Pin Count) 400 pins connector

Product Details...

vi018 – Dual 10Gb Ethernet

vi018 – Dual 10Gb Ethernet
  • TI KeyStone Multicore C667x family of processors
  • Stratix V family in the KF40 (1517 FBGA) package
  • Complies with OpenVPX MOD3-PAY-3F2U-16.2.12-2 module profile
  • Dual 10 GbE (10GBASE-T) over RJ45
  • 1.8V to 3.3V VADJ operation

Product Details...

vi019 -Dual SFP FMC

vi019 -Dual SFP FMC
  • TI KeyStone Multicore C667x family of processors
  • Stratix V family in the KF40 (1517 FBGA) package
  • Complies with OpenVPX MOD3-PAY-3F2U-16.2.12-2 module profile
  • Secondary station
  • SFP x2
  • PLL

Product Details...

vi020 – Fine Delay

vi020 – Fine Delay
  • TTL, outputs capable of driving a 50 Ohm load, > 2 V/ns slew rate
  • TDC Chip: ACAM TDC-GPX multifunctional High-end Time-to-Digital Converter
  • Timing: +/- 2.5 ppm on-board oscillator accuracy, or WR master oscillator accuracy
  • 1 inputs, TTL/LVTTL3.3 with software selectable 2kOhm/50 Ohm termination.

Product Details...
